| Power Supply and Energy Consumption |
|
| Power Input |
Configuration 1: PWR1: Phoenix terminal AC220VDC110V; 50Hz; PWR2: DC54V[12V~54V];
Configuration 2: PWR1&PWR2: DC54V[12V~54V]; Configurations are optional. |
| Allowable Range of Normal Operating Voltage |
Configuration 1: AC: [85, 265]; DC: [100, 380];
Configuration 2: DC: [12V~54V] |
| RTC |
Button battery (CR2032) |
| Total Power Consumption |
≤25W |
| System and Software Requirements |
Supports device management, log management, container management, and application software management;
Debian |
| Timekeeping Accuracy |
≤2 seconds/day |
| Minimum System |
|
| CPU Frequency |
ARM64-bit quad-core A55 processor; 2.0G main frequency |
| Memory |
4GB |
| Storage Capacity |
16GB eMMC |
| Supply Security |
|
| CPU Model |
Domestic chip (RK3568) |
| Authentication and Encryption |
Secure smart TF authentication, encryption chip data encryption, MQTT soft encryption, meeting the unified security requirements of the Ministry of Industry and Information Technology |
| Interfaces |
|
| HDMI |
x1 TypeA |
| SSD |
x1 expandable SSD, using M.2 Key M |
| Ethernet Ports |
X2; 2*1000Base-T RJ45; static IP, configurable independently |
| USB2.0 |
2 channels |
| RS-232 |
2 isolated |
| RS-485 |
4 isolated |
| DI |
4 channels |
| DO |
4 channels |
| SPI |
1 channel for encryption chip; miniPCIE |
| IIC |
1 channel for encryption chip; miniPCIE |
| TF |
1 channel for data encryption |
| Bluetooth |
miniPCIE, co-board |
| WiFi/4G/5G |
1 channel for 4G, using Mini-PCIE interface; 1 channel for 5G, using M.2 KeyB |
| LoRa Wireless Communication |
2 channels; adopt serial communication, each module reserves 3 control IO ports, Mini PCIE connector |
| Console |
1 channel Mini USB interface |
| Buttons and Indicators |
|
| Reset |
1 piece |
| Indicators |
2 bits, indicating power, operation/fault |
| Communication Indicators |
3 pieces with 2 bits, indicating status of 4G, 5G, WIFI, BT, 2LoRa; RJ45 network ports have built-in indicators, 22 pieces, indicating rate and status; |
| Communication Protocols |
|
| Remote Communication |
Supports dual stack of IPv4 and IPv6 protocols |
| Device Anti-interference Performance |
|
| Electrostatic Discharge |
Meets GB/T 15153.1 Telecontrol Equipment and Systems – Test Level 3 |
| Fast Transient Burst |
Meets GB/T 17626.4 Electromagnetic Compatibility (EMC) – Testing and Measurement Techniques – Test Level 3 |
| Radiated Electromagnetic Field |
Meets GB/T 15153.1 Telecontrol Equipment and Systems – Test Level 3 |
| Surge |
Meets GB/T 15153.1 Telecontrol Equipment and Systems – Test Level 3 |
| Table of Operating Environment Conditions |
|
| Operating Temperature Range |
-25～+70℃ |
| Humidity |
Relative humidity 0～95% (non-condensing) |
| Mean Time Between Failures (MTBF) |
≥50000h |
| Enclosure |
155mm x 115mm x 75mm |
