Industrial 4G/5G Wireless 2.4GHz Wi-Fi Router 2*10/100M Ethernet Ports SH-LTE611
Feature
- 2 x 10/100M Ethernet Ports
- Support for Industrial-Grade 3G/4G Modules
- 2.4GHz 802.11b/g/n Wireless WIFI
- Support for TDD-LTE, FDD-LTE, HSPA/UMTS, TDS, GSM/GPRS/EDGE
- Support for PPTP, L2TP, PPPoE, DHCP, Client/Server, NAPT, NTP
- Wide Temperature Range: -30°C to 70°C for Harsh Environments
- Fanless Design with High-Strength Metal Enclosure
- Desktop/Wall-Mount Installation Options
free delivery
Get free delivery in most regions. Only a few areas have extra shipping fees for your order.
secure payments
Rest assured when you shop. Our advanced encryption ensures secure payments, protecting your financial information at all times.
Return Policy
We stand by our products. You can return any item within 30 days if you’re not completely satisfied.
official products
All our products are sourced directly from official channels, offering you genuine items of the highest quality.
Product Detail
Description
Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| Radio Frequency | 4G Platform | Qualcomm MDM9225 |
| Operating Bands |
|
|
| Rate Class | CAT4 DL: 150Mbps / UL: 50Mbps | |
| Transmit Power | 23dBm | |
| Antenna | Omnidirectional Antenna, Gain 5dBi | |
| WIFI | WIFI Frequency Band | 2.4GHz, 802.11b/g/n |
| WIFI Speed | Up to 144Mbps | |
| WIFI Transmission Standard | IEEE 802.11b/g/n | |
| WIFI RF Characteristics | Max. Transmit Power 15dBm, Sensitivity Better Than -77dBm | |
| Max. WIFI Connected Users | 32 | |
| Antenna | Omnidirectional Antenna, Gain 3dBi | |
| Network Features | Network Protocols | PPTP, L2TP, PPPoE, DHCP, Client/Server, NAPT, NTP |
| High-Speed Routing | Built-in DHCP Server, DNS Client, Support for NAT Function | |
| Dial-Up Function | Support for Manual Dialing, Auto Dialing, PPPOE Dialing, etc. | |
| SIM Card Features | Support for 1.8V/3V SIM/USIM Cards. Support for Encrypted Cards, SIM Locking, and PIN Code Locking. | |
| Management | Web-Based Management | Supported |
| Centralized Network Management | Supported | |
| Remote Upgrade | Supported | |
| Remote Configuration Modification | Supported | |
| Security Features | Support for Port Filtering, IP Filtering, MAC Filtering, URL Filtering, MAC Address Binding | |
| Network Speed Control | Support for Up/Downstream Rate Limiting, Port-Based Rate Limiting | |
| Network Interfaces | LAN | RJ-45 x 2 |
| Power Supply | Power Supply | DC2.0 12V @ 1000mA |
| Power Consumption | Average Operating Power 3.0W | |
| Indicators | Indicator Type | Power Indicator, Network Indicator, Signal Indicator, LAN Indicator |
| Physical Characteristics | Operating Temperature | -30°C to 70°C |
| Storage Temperature | -40°C to 85°C | |
| Humidity | ≤95% (Non-Condensing) | |
| Dimensions | 108mm x 100.5mm x 24mm | |
| Weight | Approx. 337.5g |
